Geberit Zena urinal with integrated urinal flush control, mains operation
My list (0)
Technical data
Protection degree IPX7 |
Nominal voltage 220 V AC |
Mains frequency 50–60 Hz |
Operating voltage 6 V DC |
Power consumption standby max. 2 W |
Flow pressure 1.7–6 bar |
Test pressure, water max. 6 bar |
Operating temperature, water max. 45 °C |
Flush volume small, adjustment range 0.5 / 1.2 l |
Flow rate at 1 bar with flow limiter 0.12 l/s |
Minimum flow pressure 1.7 bar |
Calculated flow rate 0.12 l/s |
Interval flush, adjustment range 24–24 h |
Interval flush, factory setting 24 h |
Interval flush time, adjustment range 86400–86400 s |
Interval flush time, factory setting 86400 s |
Detection time, adjustment range 5–5 s |
Detection time, factory setting 5 s |
Flush time, adjustment range 3.7–7 s |
Flush time, factory setting 3.7 s |
Product material Sanitary ceramic |
Application purposes
Click on an application purpose to search more products
Characteristics
Click on a characteristic to search more products
Scope of delivery
Urinal flush control with power supply unit and solenoid valve
Fastening material
Urinal trap
Drain cover
Drain assembly
Inlet set
