Geberit GIS element for wall-hung WC, 89 cm, with Omega concealed cistern 12 cm
My list (0)
Technical data
Flow pressure 0.1–10 bar |
Operating temperature, water max. 25 °C |
Flush volume, factory setting 6 / 4 l |
Flush volume large, adjustment range 3.5–7.5 l |
Flush volume small, adjustment range 2–4 l |
Application purposes
Click on an application purpose to search more products
Characteristics
Click on a characteristic to search more products
Frame, zinc-platedFrame with four quick-action fastenersInfinitely variable height adjustment in Geberit GIS structureFrame prepared for support brackets for WC ceramic appliances with small contact surfacesConnection bend can be mounted without tools at different depths, adjustable range 45 mmConcealed cistern with top or front actuation
Concealed cistern, fully insulated against condensationImmediate post flush possible with factory settingTool-free installation and maintenance work on concealed cisternWater supply connection on the left or rear leftProtection cover box for service opening protects against moisture and dirtProtection box for service opening can be cut to length
Scope of delivery
Water supply connection R 1/2", compatible with MasterFix and MeplaFix, with integrated angle stop valve and hand wheel
Protection box for service opening
Connection set for WC, ø 90 mm
Connection bend 90° made of PE-HD, ø 90 mm
Adapter socket made of PE-HD, ø 90 / 110 mm
2 protection plugs
2 threaded rods M12
Fastening material
