Geberit Sigma concealed cistern 12 cm, 4.5 / 3 litres

My list (0)

Articles

Click on the icon with the 3 dots to have more options for each item.

Art. no.

224.326.00.1

Technical data

Flow pressure	0.1–10 bar	Flow pressure 0.1–10 bar
Water temperature max.	25 °C	Water temperature max. 25 °C
Flush volume, factory setting	4.5 / 3 l	Flush volume, factory setting 4.5 / 3 l
Flush volume large, adjustment range	4–7.5 l	Flush volume large, adjustment range 4–7.5 l

Flush volume small, adjustment range	2–4 l	Flush volume small, adjustment range 2–4 l
Product material	Plastic	Product material Plastic

Flow pressure	0.1–10 bar	Flow pressure 0.1–10 bar
Water temperature max.	25 °C	Water temperature max. 25 °C
Flush volume, factory setting	4.5 / 3 l	Flush volume, factory setting 4.5 / 3 l
Flush volume large, adjustment range	4–7.5 l	Flush volume large, adjustment range 4–7.5 l
Flush volume small, adjustment range	2–4 l	Flush volume small, adjustment range 2–4 l
Product material	Plastic	Product material Plastic

Application purposes

Click on an application purpose to search more products

For masonry walls For installation in part or room-height prewall installations For installation in room-height installation walls For floor-standing and wall-hung WCs

For single flush, dual flush or stop-and-go flush

Characteristics

Click on a characteristic to search more products

Concealed cistern with front actuation Concealed cistern, fully insulated against condensation Immediate post flush possible with factory setting Adjustable flush volume Flush bend fitted

Tool-free installation and maintenance work on concealed cistern Water supply connection on the rear or top centre Protection cover box for service opening protects against moisture and dirt Protection box for service opening can be cut to length

Scope of delivery

Water supply connection R 1/2", with integrated angle stop valve
Protection box for service opening
Flush bend
Protection plug

2 slotted flat irons
2 fixing brackets
Fastening material

Films
