SG

With push actuation PushControl

Geberit bathtub drain with PushControl push actuator d52, length 36 cm, with ready-to-fit set, PP, plastic

My list (0)

Articles

Click on the icon with the 3 dots to have more options for each item.

Art. no.
151.604.21.1
Colour / surface

chrome / glossy

DN

40

Technical data

Depth of water seal (mm)

50 mm

Application purposes

Click on an application purpose to search more products

For bathtubs made of steel, plastic or cast ironFor bathtubs with a wall thickness of up to 13 mmFor standard-size bathtubsFor bathtubs with a height of up to 610 mmFor bathtubs with drain and overflow
For bathtubs with centre outletFor bathtubs with valve hole ø 52 mmFor bathtubs with overflow hole ø 50–63 mmFor bathtubs with external trap

Characteristics

Click on a characteristic to search more products

With overflowPush actuation aligned with bathtub surfaceOverflow and outlet made of PPWith push-on sealFulfils standard requirements in accordance with ASME A112.18.2 / CSA B125.2
Fulfils standard requirements in accordance with ASTM F409Fulfils standard requirements in accordance with NSF/ANSI 14Fulfils standard requirements in accordance with cUPCFulfils standard requirements in accordance with NPCCFulfils standard requirements in accordance with ICC

Scope of delivery

  • PVC T-piece, 1 1/2"

  • Waste outlet

  • Cable actuator

  • Overflow pipe

  • Outlet pipe

  • Installation tool for trim parts

  • Fastening material

  • Ready-to-fit set made of plastic
